Name: TRAXXAS -1/10 Scale Off - Road TRX-4 Sport High Trail 4x4 - Metallic Blue
SKU: TRA82044-4BLUE
Availability: InStock

Description

Model Name:	TRX-4 Sport High Trail Edition
Model Type:	Trail / Crawler
Model Skill Level:	1
Chassis:	Steel ladder frame
Scale:	1/10
Weight:	7.04 lb (3.20 kg)
Length:	22 inches (564 mm)
Width:	10.63 inches (270 mm)
Front Track:	10.63 inches (270 mm)
Rear Track:	10.63 inches (270 mm)
Height:	10.8 inches (275 mm)

Wheelbase:	12.28 inches (312 mm)
Center Ground Clearance:	4 inches (99 mm)
Drivetrain:	Shaft-driven 4WD
Transmission:	Single speed
Differential Type:	Spool (no differential)
Gear Pitch:	32 pitch
Servo(s):	2075X metal gear, digital high-torque waterproof
Radio System:	TQ™ 2.4 GHz 2-channel transmitter
Battery Compartment Specs:	159 mm X 47 mm X 23 mm, 26 mm

Tough, Lightweight Pickup Truck Body

High-angle bumpers for increased clearance
Molded grille and tailgate
LED-ready headlights, tail lights
Full Nylon composite wheel wells and floor pans

Scale Accessories

Rugged Expedition Rack with detailed accessories
Injection-molded snorkel and side mirrors

Clipless Body mounting

Clipless design for smooth body appearance
Body details mount directly to internal frame

Trail-tuned XL-5™ HV Waterproof Electronic Speed Control

Fully waterproof design
Five drive profiles

Sport Mode — forward / brake / reverse
Race Mode — forward / brake / no reverse
Training Mode™ – 50% forward / 100% brake / 50% reverse (patented)
Trail Mode — forward / brake / reverse / with trail-tuned drag brake in neutral
Crawl Mode — forward / instant reverse – no neutral with 100% hill holding brake

Traxxas EZ-Set^® one-button setup
Large, efficient heat sink
Wide voltage latitude 6–7 cell NiMH (7.2–8.4 V) and 2–3s LiPo (7.4–11.1 V)
Two stage low voltage protection (LVD)

Titan^® 550 Motor

Powerful Titan 21T reverse rotation motor with internal cooling fan
Precision, preset gear mesh adjustments
Motor retention separate from gear mesh

Portal Axles

Increase ground clearance
Eliminate torque twist
Steel gears
Improve axle geometry and reduce strain on driveshafts

Drivetrain

Full-time shaft driven 4-wheel drive
Tough 6 mm stub axles
Steel front CV driveshafts
Hardened steel rear axle shafts
Spool-locked front and rear differentials
Steel gear transfer case

Factory-Installed Long Arm Lift Kit

Increases ground clearance over 1″
Maintains precise steering geometry
Accommodates oversize 2.2″ wheels and tires

TQ™ 2.4 GHz 2-Channel

Ergonomic transmitter with internal antenna
Traxxas 6519 3-channel micro receiver with fail-safe security
Patented O-ring sealed watertight receiver box keeps the micro receiver dry

Reinforced Steel Ladder Frame

Full-length 1.5 mm thick steel frame rails
Bumpers adjust fore and aft
Rugged rock rails adjust for width
Wire routing clips integrated into frame rails

Innovative Battery Compartment

Hinged battery strap allows quick and easy battery access
No pins to lose
Accommodates different height batteries
Accepts full-size long battery packs
Integrated compartment accepts smaller 1/16 scale batteries (with optional strap)

Transmission

Single-speed with steel gears
Dual horizontal shafts
Twin friction plate slipper clutch
Easily removed for servicing

Steering

Chassis mounted 2075X metal gear digital servo
Superior 45° steering angle
Direct steering (no servo saver)
Steering geometry corrected for bump steer

Suspension

Front — 3 link with panhard
Rear — Triangulated 4 link
Heavy-duty rod ends with steel hollow balls
5 mm diameter steel link rods with 4 mm threaded ends

Extended Aluminum GTS Shocks

Oil-filled coilover GTS shocks
Extra-long aluminum bodies for greater articulation
Silver-anodized aluminum bodies
Threaded bodies with collars easily adjust ride height
Silky smooth damping for the toughest trails
O-ring cap seal and dual X-ring shaft seals

Oversize Wheels and Tires

2.2” 5-spoke wheels with replica beadlock rings
Pre-mounted 2.2” Canyon Trail tires with trail-tuned foam inserts
Trail tuned S1 rubber compound
12 mm steel hex

Sealed Ball Bearings
Hex hardware with Rust-Resistant Black Oxide Coating
Requires Battery and Charger (Sold Separately)
