TRAXXAS Revo 3.3 4WD RTR Nitro Monster Truck (SILVER)
The Revo 3.3 Stands Alone
as the Ultimate Nitro Monster Truck
|QUICK FEATURES ON REVO 3.3 (#53097-3)|
The Revo 3.3 stands alone as the pinnacle of nitro monster truck performance. Revo’s massive power, versatility, and Traxxas innovation create the most awarded nitro truck in history. The Revo 3.3 is pure monster truck with the power to rip four-wheel roosts at will as it blasts its way to 45mph and beyond. Most importantly, Revo’s advanced engineering equips it for fun and the Revo 3.3 delivers more of it than any other nitro truck.
The Most Important Feature: Fun
Revo’s specifications are more than just an impressive list of features. They are each specifically engineered and integrated into the model to provide capability, convenience, and most importantly, fun! Revo 3.3’s heavy-duty reversing transmission lets you easily back out of tight spots with the flick of a switch, while the OptiDrive®Electronic Transmission Control guarantees safe, smooth engagement. The Traxxas TQi 2.4 GHz radio system features the exclusive Traxxas Link wireless Module with factory-installed telemetry sensors, a revolutionary concept that harnesses the power of your Android, Apple iPad, iPhone or iPod touch to create the ultimate radio system. Geode™ chrome wheels with 17 mm hex hubs wear massive 6.3″ Maxx®-sized tires for big ground clearance and total traction in all conditions. Revo 3.3’s dual-digital servo steering system delivers 250 oz.-in of torque for powerful, responsive handling, plus they’re waterproof for ultimate reliability.
100% Fully Assembled and Ready for action!
The World’s Most Advanced Ready-To-Race® Radio System Now Connects Wirelessly to the Traxxas Link App
The Traxxas TQi paired with the Traxxas Link app is the most advanced, feature-rich, Ready-to-Race® radio system available. Now, TQi connects wirelessly to the latest Traxxas Link app for the ultimate in ease-of-use and control. Equip the TQi radio system with the Traxxas Link Wireless Module to unlock exciting features such as instant Bluetooth® connectivity; access to the full range of powerful TQi tuning and telemetry tools through an intuitive high-definition graphical interface; and the ability to have a friend remotely monitor real-time telemetry while you focus on mashing the throttle. Your co-driver can even make adjustments for you, remotely, while you drive. No other radio system can do that. Just like the speed and performance Traxxas engineers into the vehicles, the power and capability of TQi and Traxxas Link expands your fun into all-new territory. Only from Traxxas, The Fastest Name in Radio Control®. Learn more about the new Traxxas TQi Radio System here.
Factory-Equipped Real-Time Telemetry
Revo 3.3 includes factory-installed telemetry sensors enabling Traxxas Link to collect and records real-time telemetry data as you drive. The Traxxas Link dashboard comes to life showing you speed, battery voltage, RPM, and temperature. The application automatically detects and recognizes Traxxas Link sensors for easy set up and configuration. The dashboard is fully customizable with either dial or digital readout gauges. Up to nine gauges can be displayed at once. Set threshold warnings and log maximums, minimums, or averages. Use the recording function to document your dashboard view, with sound, so that you can keep your eyes on your driving and not miss a single apex. If you forget to record, simply touch Instant Replay anytime to capture the previous minute of fun and unexpected triumphs. The recordings can be named, saved, and shared with others.
Intuitive iPhone and iPod touch Interface
Traxxas Link makes it easy to learn, understand, and access the powerful tuning options built into every Traxxas TQi radio system. Control your Drive Effects settings such as steering and throttle sensitivity; steering percentage; braking strength; and throttle trim by simply touching and dragging the sliders on the screen, or enabling the Multi-Function knob on the transmitter. Everything happens live, on-the-fly, giving you instant feedback on your changes.
5-channel Micro Receiver with Fail-Safe Security
The TQi 2.4 GHz micro receiver fits easily into any vehicle, and features dual channel-1 outputs for easy installation in vehicles with dual steering servos—no Y-harness necessary! The integrated LINK button makes it fast and easy to bind the receiver, and the two-color LED indicates power-on and bind status for fool-proof control and convenience. Traxxas Link Model Memory allows the receiver to recognize up to thirty TQi 2.4 GHz Traxxas Link enabled transmitters—just switch on and drive. In the event of signal loss due to an accidental switch-off or depleted batteries, the receiver will automatically return the throttle to neutral and hold the last commanded steering position. The Fail Safe programming is built-in and does not need to be set or activated. Three telemetry ports are incorporated in the 5-channel receiver to allow real-time data to be transmitted from your Traxxas model to the TQi transmitter.
Wide, Tall, Aggressive Monster Stance
The Revo 3.3’s muscular chassis and high-riding stance reflect its class-leading monster performance. Massive 6.3″ Maxx tires are the claws of this nitro-burning beast, and raise its already high ground clearance for total domination no other monster can match.
ProGraphix Painted Body
The Revo body comes fully trimmed and painted for sinister style with no finishing required. Decals are also applied to save time and get you driving just minutes out of the box. Traxxas’ ProGraphix bodies are the hottest looking lids around, with custom style even pro painters can’t duplicate.
Included NiMH Receiver and EZ-Start Battery Packs
Revo 3.3 is Ready-To-Drive™, complete with rechargeable NiMH batteries for the on-board radio gear and EZ-Start® electric engine starting system. In addition to the cost savings of replacing disposable alkaline cells with a rechargeable receiver battery, the 5-cell Traxxas NiMH 1200mAh receiver pack also provides superior performance with Revo 3.3’s high-torque digital servos. For reliable engine-starting performance, the included EZ-Start pack features rugged construction and high-capacity cells for all-day power. When it’s time to recharge, reach for the included 2amp peak detecting fast charger. Only Traxxas offers an RTR nitro monster truck package that is so complete.
Dual Digital, High-Torque,
Waterproof, Ball-Bearing Steering Servos
Revo 3.3 uses dual 2075 steering servos, each producing 125 oz.-in. of torque for a combined 250 oz.-in. of tire-turning twist. The twin servos are lighter and more compact than a single large servo, and together they deliver unmatched monster steering response and quick .16-second transit time. Digital circuitry and ball-bearing output shafts gives these servos incredibly precise centering, lightning-fast response, and superior power. And they’re waterproof! When not even water can get in, you can be sure dust and dirt don’t stand a chance.
Traxxas Geode wheels widen the Revo 3.3’s stance by a full inch for greater stability in rough terrain and superior cornering grip. The beefy six-spoke design is extra strong and uses Traxxas’ exclusive 17 mm splined hex to withstand off-road abuse. The show-chrome finish adds custom style. The Geode wheels also accept Traxxas’ beadlock-style rings (sold separately) for an instant matching or contrasting dose of color with the benefit of extra protection for the rim/sidewall joint.
6.3″ Maxx Tires
Designed for true multi-terrain versatility, the soft compound Maxx tires maximize performance for tenacious traction no matter where nitro-powered monster fun takes you. On dirt, the aggressive treads claw for traction providing superior bite and massive roosts, and on pavement the forgiving side grip allows the tire to power-slide while maintaining a sure-footed neutral feel. It’s go-anywhere performance you can only experience with a Revo.
Heavy-Duty Reversing Transmission With OptiDrive®
Only Traxxas offers a no-compromise reversing transmission with seamless power delivery, positive engagement, and smooth, responsive acceleration in forward and reverse. You get all the fun and convenience of reversing capability, without the penalty of weight and complexity inherent in an all-mechanical system. The secret is Traxxas’ exclusive OptiDrive Electronic Shift Module, a microprocessor-based controller that senses vehicle speed and optimizes forward and reverse shifting. OptiDrive allows constant drive engagement, so shifts are fast and seamless. The electronic control also prevents accidental shifting at speed; the shift module will only allow the transmission to shift when the Revo 3.3 has slowed to a safe speed. In addition to providing the absolute best performance, the OptiDrive system allows a lighter transmission with fewer moving parts for reduced inertial mass and greater torque handling.
Traxxas Top Fueler Fuel Bottle
A fuel-filler bottle is a must-have for any nitro machine, and the premium-quality Top Fueler is included with the Revo 3.3. The bottle holds a full 500 cc of fuel and features a long, angled, blue-anodized spout for easy filling.
Included Spare Glow Plug
and Air Filter Elements
Glow plugs and air filter elements are consumables in any nitro vehicle, so Revo 3.3 includes spares to keep you rolling! The premium-quality Traxxas glow plug is designed specifically for reliable, consistent operation in the TRX 3.3 engine, and the long-lasting foam filter elements are pre-oiled for convenient installation and maximum filtering performance.
TRX® 3.3 Racing Engine, Where Power Meets Technology®
The powerful TRX 3.3 Racing Engine is the heart of the new Revo 3.3, delivering thoroughbred race engine performance that’s unbeatable on or off the track. The TRX 3.3 Racing Engine features a precision composite slide carburetor, PowerTune™ cooling head, dyno-proven IPS crankshaft, multi-port rear exhaust, and the starting convenience of the exclusive Traxxas EZ-Start® system. Years of testing and proven performance deliver the easiest-to-tune, most dependable, most powerful Ready-To-Race® engine available. It’s competition-proven power with convenience and reliability for all-day driving fun.
Mirror-Polish Resonator Dual-Chamber Aluminum Pipe
The dual chamber Resonator™ aluminum pipe delivers the most broad and linear power band from the TRX® 3.3 Racing Engine. It’s dyno-tuned to deliver torque down low for hard launches off the line and big horsepower on the top end to out-rev all comers in the neighborhood drag race. The mirror-polish finish adds show-car style and stays clean longer.
Large High-Volume Dual-Stage Air Filter
Engineered to work with all Traxxas air filter bases, the new extra large dual-stage air filter increases air flow to the TRX 3.3 Racing Engine. With more air intake, the TRX 3.3 holds an incredibly consistent tune, even during long afternoons of nonstop offroad action. The dual-stage design traps large particles in the outer element, while the inner element flows clean air to the engine. The large free flowing cylindrical design allows more air to get to the carburetor, which equals more horsepower! Revo 3.3 even includes an extra set of air filter elements to extend your driving fun.
EZ-Start® Electric Starting
Only the Traxxas EZ-Start offers the pure convenience of true one-handed operation and complete on-board, push-button electric starting. The Traxxas EZ-Start lights your glow plug and starts your engine quickly and smoothly at the push of a button. Traxxas’ exclusive Smart Start™ technology monitors critical starting functions, automatically sensing and diagnosing potential problems for troublefree engine starting every time! LEDs provide realtime status, even alerting you when a glow plug has failed. Revo 3.3 includes the required 6-cell battery and 2-amp peak deteting fast charger to power the EZ-Start system for total convenience.
150 cc Fuel Tank
Revo 3.3’s extra-large fuel capacity lets you run longer between pit stops for more driving fun from every tankful. In addition to adding capacity and run time, the new 150 cc tank has been carefully engineered to seal properly every time for consistent tuning. Inside, specially developed baffles and a sump design make sure fuel continues flowing even during the most extreme maneuvers.
Hard-anodized, PTFE-Coated GTR Shocks
The ultimate shocks for Revo, standard equipment on the new Revo 3.3. Ultra-long lasting hard-anodized, PTFE-coated aluminum GTR shocks represent the pinnacle of off-road performance, offering silky smooth damping and a serious factory-works look. Thanks to the extra tough hard-anodized finish, shock performance stays true and consistent for less maintenance and better handling, run after run.
Smooth and Durable TiN Shock shafts
Titanium Nitride coated shock shafts deliver ultra-smooth damping with nearly friction-free operation for incredibly responsive suspension action and extra long seal life. The durable titanium nitride finish offers durable, smooth, long-lasting performance.
Aluminum 17 mm Splined Wheel Hub and Hex Nut
Traxxas 17 mm hubs and wheel nuts provide precision alignment and unsurpassed torque handling. The splined design interlocks with the Geode wheels for a solid fit that holds tight. The ground-breaking new design also accepts traditional aftermarket 17 mm hex wheels, and an easy-to-use molded wheel wrench is included for easy wheel removal and installation.
Large 6×13 mm Outer Axle Bearings
The Revo 3.3’s axle carriers utilize large 6×13 mm outer ball bearings for improved static load and stress resistance. The large, durable, rubber-sealed ball bearings are designed to handle hours of nitro off-road action with minimal maintenance.
Steel Pivot Ball Retainers
Strong steel retainers keep the pivot balls in place even after the most brutal crash. The new axle carrier design provides all the benefits of aftermarket aluminum carriers without the penalty in weight and cost.
3D Semi-Monocoque Chassis
Revo 3.3’s extended chassis design merges engineering artwork with functionality for incredible stability on rough terrain. The unique monocoque chassis is cut and formed from 3 mm, 6061-T6 aluminum for a combination of rigidity and light weight that flat-plate designs can’t match. The engine cradle and deep channel design provide superior strength without adding unnecessary weight, and an integrated chassis brace prevents flexing caused by engine torque.
Large Diameter Disc Brake
A large 42 mm steel rotor spins between two unique semi-metallic brake pads which, when engaged, bind the drilled steel disc for powerful 4-wheel braking action. The proven design provides fast fade-free braking to bring Revo 3.3 to a stop almost as quickly as it accelerates.
Sealed Limited Slip Differentials
The Revo 3.3 features sealed, bevel-gear differentials that are filled with silicone fluid to offer a broad range of tuning options. Precision-sealed with Traxxas X-ring silicone seals, the Revo 3.3 differentials are designed for long-lasting performance and the ability to tune for specific running conditions by varying the viscosity of the fluid inside them. Built to handle extreme torque and power, these differentials offer unmatched versatility and toughness.
Super-Duty Sealed Driveshafts
The reliable and incredibly tough Revo Drivetrain utilizes sealed super-duty driveshafts throughout the driveline. Expandable rubber seals prevent friction-causing dirt from entering the half shafts. True curvilinear splines provide smooth performance and large rubber-sealed stub axle bearings are used for long-lasting, smooth running performance. Revo’s sliding half shaft design is clearly superior, eliminating the metal-to-metal drive pin plunge friction that speads wear in typical metal driveshafts and the possibility of bent shafts. Plus, there’s no need to limit suspension travel just to keep the drive pins from popping out of the cups. Revo’s driveshafts are engineered for durable, smooth, maintenance-free operation.
Sealed Pivot Ball Suspension
Traxxas’ exclusive rubber-sealed pivot balls maintain factory smooth performance even in the harshest environments. The unique design allows easy adjustment and unmatched reliability. The heavy-duty axle carriers use large diameter rubber-sealed bearings for ultra-smooth running that’s practically maintenance-free.
Progressive-2 Rockers for Balanced Handling in All Conditions
Chosen specifically to optimize Revo’s advanced suspension geometry, Progressive-2 rockers provide balanced bump absorption and chassis response for the best all-around performance on a wide variety of surfaces. For extreme off-roading, Long Travel rockers and springs are provided to boost Revo 3.3’s suspension travel from a plush 90 mm to a full 120 mm for seemingly bottomless suspension travel.
The Most Suspension Travel
Revo architecture delivers the most suspension travel possible, tunable progressive damping rates, independent ride height adjustment, and the absolute highest level of control for any situation. The precision hard-anodized aluminum shocks are rigidly mounted to the chassis, protected from dirt, rocks, and crash damage.
With its massive new Maxx tires, Revo 3.3 delivers over 4″ of center ground-clearance for go-anywhere performance. Integrated skid plates protect the driveline from rocks and hard impacts.
Rubber-Sealed Ball Bearings
Precision rubber-sealed bearings offer the ultimate in super low-friction performance and maximum protection in dirt and nitro environments. They are used in all exposed locations on the truck and are virtually maintenance free.
Pro-quality, high-grade, metric hex-drive hardware is used throughout for extra strength and easy maintenance and repair. The black-oxide rust-resistant finish provides a high tech look and feel.
